Description
APPLICATIONS
- For stitching light and medium weight fabrics, leather, canvas, vinyl and various coated and laminated materials
- Designed for stitching such uneven articles as raincoats, underwear, brassieres and similar products.
- Suitable for vamping, space stitching, tipping, etc. on shoes.
FEATURES
- Centra-Lube® semi-automatic lubrication system
- Oil fed take-up
- Stitches per minute – 2400*
- Safety clutch prevents the hook from being damaged
- Reverse stitching
- Large vertical axis rotary hook and bobbin
- Roller presser foot aids in the turning of corners and sharp curves
SPECIFICATIONS
| Number of Needles | 1 (Single) |
| Feeding Mechanism | Needle Feed |
| Workspace | Standard Workspace |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 2400 |
| Clearence Under Presser Foot | 15/64″ (6mm) |
| Stitch Length | 4.2 s.p.i. (6mm) |
| Needle | 135 x 17 |
| Bobbin | Pre-Wound S and U |
| Stitch Type | 301 |
| Needle Bar Stroke | 1 5/16″ (33mm) |
| Hook | 14005 |
| Post Height | 7″ (178mm) |
| Work Surface | 2 1/8″ x 2″ (54mm x 51mm) |
